High Frequency, High Current and Standard Designs – to 40 GHz – for Signal Processing Applications
TTE will introduce a new line of Bias Tees at IMS2015. The line includes three series:
- BTHF – high frequency series for 10 MHz to 40 GHz
- BTHC – high current series for 500 MHz to 4 GHz and current handling to 7 A DC
- BTS – standard series for 10 MHz to 18 GHz
All three series provide very low insertion loss, minimal return loss, desirable VSWR characteristics and extremely flat gain response over the series-specific frequency ranges. The products are manufactured using high-quality components and processes to deliver superior broadband performance. A summary data table is provided below. RoHS-compliant parts are available upon request.
Please refer to series datasheets for the most up to date information in case any data has changed since the news release issued.
|TTE Filters Bias Tee Part Number||Frequency Range (GHz)||Insertion Loss Typ (dB)||Return Loss Min (dB)||VSWR Min||DC Port Isolation Min (dB)||DC Current Max (mA)|
|BTHC*-4G||0.5 – 4||0.7||15||1.5 : 1||25||7000|
|BTHC*-6G||0.2 – 6||0.7||15||1.4 : 1||25||3000|
|BTS*-5G||0.01 – 5||0.7||15||1.5 : 1||25||1000|
|BTS*-11G||0.01 – 11||0.7||15||1.5 : 1||25||1000|
|BTS*-18G||0.01 – 18||0.7||15||1.5 : 1||25||500|
|BTHF*-27G||0.01 – 27.5||1.3||15||1.5 : 1||25||500|
|BTHF*-40G||0.01 – 40||2.5||12||1.7 : 1||25||250|
*For RoHS compliant, insert “R” in place of asterisk. Example: BTHCR-4G
Meet Dave Zavac at IMS 2015 Booth #717
TTE Filters announces the hiring of David Zavac as Sales Manager. Zavac worked for TTE for almost 18 years before leaving the company to pursue other opportunities in 2012. TTE Filters has rehired him to oversee the company’s sales, customer relations and sales channels.
“Dave is well known to many individuals and organizations in the signal processing and communication industry. Many of our customers have already mentioned how happy they are to know he has returned to TTE since they appreciate his work ethic, follow through and attention to detail,” said Claude Badawy, President at TTE.
“I’m excited about rejoining TTE and look forward to working closely with our customers to address their need for high performance filters that are provided with fast turnaround time and excellent customer service,” said Zavac.
Zavac will be available for comment at the upcoming International Microwave Symposium (IMS2015) being held in Phoenix, Arizona the week of May 17th. Please stop by Booth #717. He can also be reached at +1-716-228-0128 or via email firstname.lastname@example.org.
The Lowpass Chebyshev LC9S Passive Filter Series Addresses the Need for Off-The-Shelf Convenience
TTE has been manufacturing filters in the USA since 1956 and has particular expertise in short lead times. Expedited lead time as short as 3-5 days is available on many built-to-order filter designs. TTE’s new LC9S is a high quality filter series offered from inventory with competitive pricing and same day shipment. This series addresses the market need of customers requiring immediate delivery – when 3 to 5 days is not fast enough.
The 9-pole filters in the LC9S Series deliver fast roll-off, an insertion loss of 1.0dB maximum and 50 Ohm terminations. Nine part numbers are available, each at a specific -1dBc passband frequency, from 30 MHz to 3 GHz. Continue reading “TTE Introduces Stock Filters for Immediate Shipment – LC9S Series” »
